Advanced Features
User’s Guide 23
7 To define the filter’s target area:
a When the Activate button is
illuminated (default), move
the cursor over the image
area.
b Draw the filter boundaries by
clicking and moving the
mouse to each corner of the
target area and clicking
again.
c After enclosing the target
area, click again to fill shape.
d Click the Deactivate button to
create a hole in the target
area.
8 Set the sensitivity level.
Note
Sensitivity is based on the size of the highlighted area. At higher sensitivity settings, smaller
changes trigger the filter. At lower settings, larger changes are required to trigger the filter.
Therefore, a large area may require a higher sensitivity for a small amount of movement.
9 Click Apply.
Searching Using Text Associated with Cameras
1 From the Search Mode page, click Text Streams. The search dialog displays criteria tabs:
Date/Time, Text Streams, and Text Criteria.
2 Select String Search or Advanced Search (does not apply to Intellex IP). The displayed tabs
depend on the text search selected. Advanced Search adds the Receipt Definitions tab.
Searching by String
You can search for any string associated with the Intellex or camera.
1 Select String Search.
2 Select the Date/Time tab.
3 Enter Date/Time criteria (optional).
4 Select the Text Streams tab to enter text stream criteria. You can:
• Select Any Text Stream to search all text streams on the Intellex unit
•Select Specific Text Stream. Select a stream from the list.
5 To define your search, click Text Criteria.
Advanced Searches
1 Select Advanced Search.
2 Select the Date/Time tab.
3 Enter Date/Time criteria (optional).
