American Eagle 30P - 30 P Assembly Bill (PN 66338)

American Eagle
®
30P Compressor Manual | Page 13
30P Assembly Bill - PN 66338
ITEM
PART
DESCRIPTION
QTY.
1 0333
NUT 0.25-20 HHGR5 NYLOC
2
2 0335
CAP SCR 0.38-16X1.25 HHGR5
8
3 0339
CAP SCR 0.25-20X2.50 HHGR5
2
4 0340
WASHER 0.25 FLAT
4
5 0347
NUT 0.38-16 HH NYLOC
6
6 0351
CAP SCR 0.38-16X1.00 HHGR5
6
7 0479
CAP SCR 0.25-20X0.75 HHGR5
4
8 0482
CAP SCR 0.25-20 X 3.00 HHGR5
2
9 0521
WASHER 0.25 LOCK
6
10 0523
WASHER 0.38 LOCK
10
11 0560
FTG 6 MFS PLUG
1
12 12180
FILTER MANIFOLD SHD60 CPRSR
1
13 12813
GROMMET 1.25ODX0.125X0.625ID
1
14 13523
CPRSR V480CT66NP
1
15 13529
FILTER AIR SHD60
1
16 13577
CLAMP UNI 1.19 O.D. 5019
4
17 13638
FTG 12-12 HB-MP 90 MODIFIED CUT
2
18 14267
TUBING COPPER 0.25 X 9.00
1
19 14600
HOSE SUCTION 0.75 X 13.00
2
20 18611
SCREW #6-32X0.38 HH MACH SELF TAP
2
21 19589
NUT SERT 0.25-20X0.38 OD
2
22 19592
WASHER 0.25 FLAT NYLON
1
23 19644
BRKT MOTOR MOUNT 19644 POWDERCOAT
1
24 20451
FTG 2-2 MP-FP STREET ELBOW 90 BRASS
1
25 21393
FTG 12-12 FP-MJ BULKHEAD STRAIGHT
1
26 22183
SCREW #8-32X0.75 BTNHD SS
2
27 22186
NUT #8-32 HH NYLOC SS
2
28 2772
CAP 8FNL-S
1
29 28855
HOUR METER 12VDC TST 180-1911
1
30 3864
FTG 12-12 MJ-MP 90
1
31 4581
NIPPLE 0.75X4.00 BRASS
1
32 51841
MOTOR HYD SHD60 & SHD43 1.93 CID
1
33 5290
WASHER #8 SAE FLAT
8
34 5480
VALVE CHECK 0.75 STANDARD
1
35 61792
MANIFOLD ASM SVRV10-12SAE 3000PSI ALUM BODY
1
36 65025
FTG 12-12 MFS-MFS BULKHEAD UNION
1
37 66331
TUBE ASM 0.50 BLKHEAD TO MANIFLD SHD 21-60 ZC
1
ITEM
PART
DESCRIPTION
QTY.
38 66332
TUBE ASM 0.50 MANIFLD TO MOTOR SHD60 ZC
1
39 66333
TUBE ASM 0.75 MANIFLD TO COOLER SHD60 ZC
1
40 66334
TUBE ASM 0.75 MOTOR TO COOLER SHD60 ZC
1
41 66335
TUBE ASM 0.75 COOLER TO BLKHEAD SHD60 ZC
1
42 66337
BASE WLDMT SHD43/60 STL SHROUD
1
43 66354
SHROUD ASM CPRSR SHD43/60
1
44 66991
PLATE AL 61792 MANIFOLD MOUNT
1
45 67510
TUBE ASM 0.75 AIR CPRSR TO BLKHEAD SHD60 ZC
1
46 73652
PLUG NICKEL PLATED BUTTON 0.88
1
47 76364
WIRE HARNESS 30R/45R/65R CPRSR
1
48 77503
PANEL BULKHEAD 30P PC WHITE
1
49 78190
HOSE 0.38(200PSI)-6PL SHORT-6PL STRAIGHT-
23.5CL
1
50 8276
FTG 4-2 MP-MP 90
1
51 8278
FTG 12-12 FP-MP W/ .125 FP SPL
1
52
B0682
BRKT COOLER MOUNT SHD60
1
53
C0081
CLAMP 0.50 BLK VINYL
1
54
C0863
SWITCH PRES COMPRESSOR
1
55
C0944
CAP SCR 0.38-16X1.75 HHGR5
2
56
C1129
COOLER OIL
1
57
C1180
FTG 8-12 MFS-MORB STRAIGHT
1
58
C2053
FTG 12-8 MORB-FORB STRAIGHT REDUCER
1
59
C3480
COUPG HYD CPRSR TAPER
1
60
C4570
CAP SCR 0.31-24X0.75 HH NF
1
61
C4779
COUPG SPIDER SUL 99 BLUE URETHANE
1
62
C4781
COUPLING LOVEJOY 5/8
1
63
C4794
FTG 12-12 HB-MAORB 45
2
64
C4909
FTG TEE SL LOK 8-S5OLO-S
1
65
C5616
CLAMP ROMEX 0.50
2
66
C5968
FTG 12-12 MFS-MAORB 90
4
67
C6021
CAP SCR 0.25-20X0.75 BTNHD SS
1
68
C6353
WASHER 0.38 FLAT GR8
12
69
C6359
FAN 12.00 PULL 12 VOLT
1
70
D0075
SCREW #6-32X2.75 RH HD MACHINE
2
71
D0076
NUT #6-32 HH NYLOC
2
72
D0525
FTG 12-12-12 MFS-FFSS-MFS RUN TEE
1
73
D1318
FTG 8-8 MFS-MFS BULKHEAD UNION
1
74
D1345
FTG CPRSN 0.12NPT/0.25 TUBE
1
75
D1465
WASHER 0.31-0.178 THICK
1
76
new
Square D
copper
tube
1
