American Eagle 30P - Optional Head Unloader

Page 20 | American Eagle
®
30P Compressor Manual
PN 23200
ITEM PARTDESCRIPTIONQTY. ITEM PARTDESCRIPTIO
NQ
TY.
122591 BODY HEAD UNLOADER CPRSR160220CAP SCR 0.25-20 X 1.50 HHGR
55
222599 GASKET UNLOADER1722596 CAP SCR 0.38-16X4.00 SH HEAD BOLT1
322593 PISTON HEAD UNLOADER CPRSR28C0040 WASHER HD BOLT ST
L1
422598 O'RING 2-116 HEAD UNLOADER CPRSR4 922597 SPRING PLUNGER PIN UNLOADER CPRSR2
522592 COVER HEAD UNLOADER CPRSR110 22594PIN PLUNGER HEAD UNLOADER CPRSR2
Optional Head Unloader
