AMETEK CTS Automotive Transient Immunity Testing
1.00 13 / 26
10 Earth plug for verification (select generators only)
This earth plug can be used during pulse verification special for pulse 3a/3b verification.
11 LED Battery Switch (select generators only)
The red LED shows whether the battery switch is off or on. For negative pulses the battery switch is switched
OFF during pulse generation.
12 LED Pulse at +output
The LEDs show the type of pulse (micro pulse or burst) and at which output they are carried out.
13 LED Burst 3a/3b pulses
Generators with multiple outputs usually have an LED to indicate which connector is active.
Burst and micro-pulses could be carried out at different outputs.
14 TEST SUPPLY
Test Supply output to DUT.
The DUT is powered via the safety lab connecors at the front panel of the simulator. The transient test pulses
are superimposed onto the battery supply voltage inside the generator.
