5. Operation 200-series 19” units using front panel control
Most simulators are
operated by an easy menu control system. Seven
function keys are available to select parameters and functions. All functions
are indicated on the display; max. 8 lines and 40 characters.
The selected parameter is blinking and can be changed by turning the knob (incr./decr.).
: The digit to be changed can be selected with the cursor ().
- Setted values are direct indicated on the screen.
- Status on the bottom lines shows the desired status after pressing the function key.
ESC : ESC will take you back to the previous level in the menu and set the displayed values. The latest settings
are stored automatically and will be recalled when the menu is selected again.
EXIT : The firmware will reset to the main screen.
Micro Pulses 1, 2
Burst Pulses 3a, 3b
Freestyle
The generator type, serial number and the version
number SWN are shown on the main screen
. These
numbers are listed in the test reports and calibration
certificates.
Automotive Transient Generator
5.1. Manual Operation
5.1.1. Main Menu
The main menu is where pulses are selected, and will vary by generator. Here you can also select the Service
menu.
F1 : Pulse 1 F4 : Freestyle
F2 : Pulse 2 F5 : External
F3 : Pulse 3a / 3b F6 : Standards
5.1.2. Service
F1 Addresses
Here you will find addreses for service and support
organizations
F2 Selftest
Together with the user the firmware can test some parts of the equipment. The software will clearly explain the self-
test procedure.
