Ametek BROOKFIELD CT3 User Manual

AMETEK Brookeld Page 11 Manual No. M08-372-F1116
1) USB TYPE B PORT
Use with USB Cable P/N DVP-202 to connect instrument to a computer. Cable USB 2.0 A Male
to B Male. See Appendix D, (CT3 to Computer Command Set)
2) RS-232 Serial Port
Use with RS-232 Cable P/N DVP-80 to connect instrument to a computer.
See Appendix D, (CT3 to Computer Command Set).
3) Temperature Probe Plug - 4 pin plug. Use with Temperature Probe P/N DVP-94Y
4)PowerEntryModule:ON/OFFswitch-fused(seeI.2Utilities).Voltage:90-265VAC
I.8 Cleaning
InstrumentandKeypad: Cleanwithadry,nonabrasivecloth.Donotusesolvents
or cleaners.
ProbesandFixtures: Probesandxturesaremadefromavarietyofmaterials
from metals (stainless steel, aluminum) to plastics (acrylic,
Black Delrin, Nylon). Clean with a nonabrasive cloth
using solvents that are appropriate for both the sample
materialandthematerialoftheprobeand/orxture.
 Donotapplyexcessiveupward,downwardorsidewaysforcetoprobewhilexedto
CT3. Damage may occur to the load cell.
