AMETEK Brookeld Page 20 Manual No. M08-372-F1116
PEAK LOAD: 234.0 g

DEF@PEAK: 123.5 mm
WORK: 1.77 mJ
FINAL LOAD: 344.0 g
PEAK LOAD: 234.0 g
WORK: 1.77 mJ
FINAL LOAD: 344.0 g
ADH. FORCE: 99.0 g


PEAK LOAD: 234.0 g
FINAL LOAD: 344.0 g
ADH. FORCE: 99.0 g
ADHESION: 2.54 mJ


PEAK LOAD: 234.0 g

ADH. FORCE: 99.0 g
ADHESION: 2.54 mJ
TEMP: 100.3 C
Figure III.9
HOLD TIME TEST - performs a single compression of the sample. The sample remains
compressed for programmed hold time before the probe returns to starting position.
The operator sets the hold time, trigger value, target deformation and test speed using the Hold
Timemenuscreen:
TEST:HOLD TIME: XXXX S
TRIGGER: XXX.X
g
DEFORMATION: XXX.X
mm
SPEED: XX.X mm/S
Figure III.10
A hold time test performs a single compression cycle when the operator depresses the start button.
The test runs at the programmed test speed to the target deformation, then holds at this position
while monitoring sample load for the programmed hold time. The countdown clock shows remaining
holdtime.Duringthetest,therunningscreenisseenasshownbelow:
TEST:HOLD TIME: XXXXS
DEFORMATION:XXX.X mm
LOAD: XXXX.X g
Figure III.11
Deformation and Load will remain live displays during the test. When the countdown clock
reaches zero, the probe returns to home/starting position at 4.5mm/s.
