Ametek BROOKFIELD CT3 User Manual

AMETEK Brookeld Page 7 Manual No. M08-372-F1116
TriggerPoint:
Range Resolution
Model Grams Grams
CT3-100 0.1-10 0.01
CT3-1000 0.2-100 0.10
CT3-1500 0.2-150 0.2
CT3-4500 0.5-500 0.5
CT3-10KG 1-1000 1.0
CT3-25KG 2-2500 2.0
CT3-50KG 5-5000 5.0
Recommended trigger value settings are given in Table II.1.
NOTE: Setting a trigger value of zero disables trigger function so test will immediately start
from current position.
Speed: 0.01to0.1mm/sinincrementsof0.01mm/s
0.1 to 10 mm/s in increments of 0.1 mm/s
 Accuracy:±0.1%ofsetspeed
Position: Range:0-101.6mm
 Resolution:0.1mm
 Accuracy:0.1mm
Increments for changing test speed using the Select/Scroll knob can be switched between
0.1mm/s and 1.0mm/s by depressing Reset/Stop button.
Temperature: -20°Cto120°C(Requiresoptionalprobe,DVP-94Y)
Output: RS232CompatibleSerialPort,USBPort
Environmental 0°C to 40°C temperature range (41°F to 104°F)
Conditions: 20%-80%relativehumidity,non-condensingatmosphere
Use: Intendedforindooruseonly
 Altitude:upto2000m
Dimensions: 10.5”x10.5”x24”
Weight: 37lbs.(16.8kg)
I.5 Installation
1) Prepare a clean, level surface.
NOTE: This instrument is a sensitive force measuring device. It should be installed on a clean,
solid, level bench surface which is free from external vibrations.
2) Unpack and remove the CT3 Texture Analyzer from the shipping container.
The CT3 Texture Analyzer weighs 16.8 kg (37 pounds). Use caution when lifting the
unit out of the packaging.
