AMETEK Brookeld Page 46 Manual No. M08-372-F1116
Appendix A - Probes, Fixtures, Calibration Accessories and Gelatin Accessories
Thissectionprovidespartnumbersanddetaileddescriptionsforthetestprobesandxturesthatcan
be used with your CT3 Texture Analyzer. Also included is information on calibration accessories and
the equipment used to perform gelatin Bloom tests.
A-1 Probes
SELECTED PROBE KITS
TA-P-KIT2 RECOMMENDED GENERAL PROBE KIT
Includesthefollowingprobes:60degreeconeTA2/1000;12.7mmcylindrical
(BS std) TA5; 60mm wide knife edgeTA7; 1.0mmdia needleTA9; 12.7mm
cylindrical(AACCstd)TA10;25.4mmcylindrical(AOACstd)TA11/1000;45
degree cone TA15/1000; 30 degree cone TA17; 12.7mm ball TA18; 50.8mm
cylinder TA25/1000; 0.33mm cutting wire TA53; 2mm rod TA39; 38.1mm
cylinderTA4/1000;6mmcylindricalTA41;25.4mmballTA43;4mmcylinder
TA44 and TA-PCC
TA-P-KIT3 CURD PROBE KIT
Includesthefollowingprobes:5mmdiscTA46;8mmdiscTA-47;10mmdisc
TA48 and storage case.
CYLINDER / ROD PROBES
* included in TA-P-KIT2
TA3/100 25.4mm DIAMETER CYLINDER PROBE
Clear Acrylic. 35mm Long. Rad .35 - .43mm (Low mass for CT3100)
TA3/1000 25.4mm DIAMETER CYLINDER PROBE
Clear Acrylic. 35mm Long. Rad .35 - .43mm.
TA4/100 38.1mm DIAMETER CYLINDER PROBE
Clear Acrylic. 20mm Long. Rad .35 - .43mm. (Low mass for CT3100)
TA4/1000 * 38.1mm DIAMETER CYLINDER PROBE
Clear Acrylic 26g. 20mm Long. Rad .35 - .43mm.
TA5 * 12.7mm DIAMETER CYLINDER PROBE
Black Delrin 5g. 35mm Long. Rad .35 - .43mm.
TA6 6.35mm DIAMETER CYLINDER PROBE
Black Delrin. 20mm Long. Rad .35 - .43mm. . (Low mass for CT3100)
TA10 * 12.7mm CYLINDER PROBE
Clear Acrylic 5g. 35mm length with sharp edge. Gelatin Bloom Probe
