AMETEK Brookeld Page 6 Manual No. M08-372-F1116
NOTE: Optionalcomponentsmayincludeprobesorxtures.SeeAppendixAfordetails.
I.2 Utilities
InputVoltage: 90-265VAC
InputFrequency: 50/60Hz
PowerConsumption: 150VA
Fuse: Two4amp,5x20mm,Time-lag
PowerCordColorCode:
United States Outside United States
Hot (live) Black Brown
Neutral White Blue
Ground (earth) Green Green/Yellow
Mainsupplyvoltageuctuationsarenottoexceed±10%ofthenominalsupplyvoltage.
I.3 Units
The CT3 Texture Analyzer uses the SI system of units for all parameters.
Parameter Unit Abbreviation
Load Grams or Newtons g or N
Deformation Millimeter mm
Time Seconds s
Speed Millimeter per second mm/s
Work MilliJoules mJ
I.4 Specications
Load:
Range Resolution
Model Grams Grams Accuracy*
CT3-100 0-100 0.01 ±0.5%FSR
CT3-1000 0-1000 0.10 ±0.5%FSR
CT3-1500 0-1500 0.20 ±0.5%FSR
CT3-4500 0-4500 0.50 ±0.5%FSR
CT3-10KG 1-10000 1.0 ±0.5%FSR
CT3-25KG 2-25000 2.0 ±0.5%FSR
CT3-50KG 5-50000 5.0 ±0.5%FSR
FSR = Full Scale Range
*Thisvalueappliestothefullrangeofoperatingtemperaturesasdenedlaterinthissection
underEnvironmentalConditions.Accuracyis0.1%FSR,whentheinstrumentisoperated
in a stable ambient temperature (20°C - 25°C).
