AMETEK Brookeld Page 24 Manual No. M08-372-F1116
The operator sets the trigger value, target deformation and the test speed using the Tension menu
screen:
TEST: TENSION
TRIGGER: XXX.X g
DEFORMATION: XXX.X mm
SPEED: XX.X mm/s
Figure III.22
AfterpressingStarttheoperatorispresentedwiththisreminderscreen:
*ATTACH TENSION
FIXTURES
*PRESS START
TO CONTINUE
Figure III.23
BesuregripsorothersamplexturesaresecureandalignedthenpressSTART.TheScroll/Select
knobnowbecomesatoolforadjustingthepositionofthegripssothatthesamplecanbeclamped.
Rotateknobtomove1mm/clickorholdknobdowntodescendat4.5mm/s:
*ADJUST POSITION
USING SCROLL/SELECT
*PRESS START
DEFORMATION:XXX.X mm
Figure III.24
The deformation value shown in this screen is the current distance from the top Home position and
as such shows how much travel is possible once the test begins. Be sure this value is greater than
the sum of the distance necessary to reach the trigger plus the programmed target deformation.
When clamping the sample try to exert only minimal lateral loads on the probe shaft. Pressing Start
asshownbelowwillstartthetest:
*CLAMP SAMPLE
*PRESS START
TO CONTINUE
Figure III.25
Duringthetesttherunningscreenisseenasshownbelow:
TEST: TENSION
DEFORMATION:XXXX.X mm
LOAD: XXXX.X g
Figure III.26
