Ametek BROOKFIELD CT3 User Manual

AMETEK Brookeld Page 49 Manual No. M08-372-F1116
TA38 10mm DIAMETER BALL PROBE
Stainless Steel.
TA43 * 25.4mm DIAMETER BALL PROBE
Nylon 14g
TA49 25.4mm DIAMETER ROUND END
Clear Acrylic.
TA50 5mm DIAMETER BALL PROBE
Surimi application
MISCELLANEOUS PROBES
* included in TA-P-KIT2
** included in TA-P-KIT3
TA-DGF001 DUAL GRIP FIXTURE
These are multipurpose general grips for tensile type testing. The 25mm wide
gripsaretted with rubberinserts tomaximisecontactadhesionwith sample
and are capable of holding rectangular samples up to 5mm thick. Each grip
clamps from both sides of sample with two opposing thumbscrews for precise
alignment. Includes one pair of T-Bolts for mounting to base. Base table kits are
NOTUSEDwiththisxture.
TA7 * KNIFE EDGE
Clear Acrylic 8g. 60mm Wide.
TA9 * NEEDLE PROBE
Stainless Steel. 1.0mm Diameter. 43mm Long.
10º Maximum Taper.
TA22 18SWG BAR FRAME PROBE
Aluminium Frame. 39mm Wide.1.2mm Dia
TA23 12.7mm DIAMETER ROUND END PROBE
Black Delrin. 35mm Long.
TA46 ** TA CURD PROBE 5mm
Stainless Steel, 5mm dia disc ( 0.2 sq cm )
TA47 ** TA CURD PROBE 8mm
Stainless Steel, 8mm dia disc ( 0.5 sq cm )
TA48 ** TA CURD PROBE 10mm
Stainless Steel, 10mm dia disc ( 0.8 sq cm )
TA37 2.36mm DIAMETER CUTTING WIRE PROBE
Aluminium Frame. 40mm Wide.
