AXB-F117 Stealth 1 Camera Controller Pre-Installation Settings 11
7. Carefully place the back panel onto the main unit and align the screw holes.
Make sure the cables are not pinched in the back panel or drive gears.
8. Insert the four pan-head screws and tighten.
Note
The communication settings
for RS-232 mode are:
• 9,600 baud
• No parity
• 8 bits
•
1 stop bit
