16 Installation AXB-F117 Stealth 1 Camera Controller
5.0"
(127.0 mm)
4.0"
(101.6 mm)
4.0"
(101.6 mm)
5.0"
(127.0 mm)
5/8" (.625")
(15.9 mm)
1.0"
(25.4 mm)
18.0"
(457.2 mm)
3.0"
(25.4mm)
Pan/tilt mounting plate
Wall mounting plate
5. Mount and balance the camera and lens on the AXB-F117.
Figure 18
WM-CAM Wall Mount kit
mounting dimensions
(front view)
Figure 19
WM-CAM Wall Mount kit
dimensions (side view)
