Chapter 1: Introducing Your New N8000
Hardware Overview
N8001 N-Command Controller
Refer to Figure 1 as well as the Front and Rear Panel Descriptions table on page 8 for hardware details on the N8001 N-Command
Controller.
FIG. 1
N8001 Front and Rear Panel
N8002 N-Command Controller
The N8002 is built from a standard computer, but not all buttons, LEDs, and connectors are enabled. Refer to Figure 2 as well as the
Front and Rear Panel Descriptions
table on page 8 for hardware details on the N8002 N-Command Controller.
FIG. 2
N8002 Front and Rear Panel
RJ-45 auto-sensing gigabit ethernet port
Power On/Off Switch
Power Input
Power
ON/OFF
button and
POWER
LED
Two RJ-45 auto-sensing
Power Input and On/Off Switch
gigabit ethernet ports
(
Eth0
on the left and
Eth1
on the right)
