You can remove cylinder units from each channel of the MPB for cleaning or

replacement.

・Remove the ejector, push both cylinder detachment switches to release the lock

then pull out the cylinder unit.

・To install a cylinder unit, extend the piston of the cylinder unit and insert until the

cylinder detachment switch locks.

13-3 After maintenance performance check

After replacing the lower part or cleaning the tip holder it is recommended that checks

to ensure volume and proper functioning be conducted through use of Leak Tester

(AD-1690) and Pipette Accuracy Tester (BM series with BM-014, AD-4212A-PT,

AD-4212B-PT, FX-300i-PT, etc., sold separately).

Refer to “17-4 Inspection equipment”

Cylinder unit

Press both cylinder

detachment switches

Piston

Insert until the cylinde

detachment switch locks.
