English - 73 -
Note that if you use a decoder or a media recorder, you should connect the aerial cable
through the device to the television with an appropriate antenna cable, as shown in the
illustrationin the following pages.
DC 12 V Input 6. is used for connecting the supplied power adaptor.
V+
V+
V-
V-
.
Audio Line Outs 7. output audio signals to an external device such as an optional sound
system.
To connect the external speakers to your TV, use AUDIO LINE OUTS of the TV with an
audio cable. Note: Line out feature cannot be used while in HDMI source. You can use
SPDIF instead.
PC Input8. is for connecting a personal computer to the TV set.
Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.
HDMI 1: 9. HDMI input
HDMI Input is for connecting a device that has an HDMI socket.
Your LCD Television is capable of displaying High Defi nition pictures from devices such as a
High Defi nition Satellite Receiver or DVD Player. These devices must be connected via the
HDMI sockets or Component Socket. These sockets can accept either 480i, 480p, 576p,
576i, 720p, 1080i, 1080p signals. No sound connection is needed for an HDMI to HDMI
connection.
When you use the wall mount kit (optional) with the LCD TV, we would defi nitely recommend to
plug all your cables into the back of the LCD before mounting to the wall.
