Andrew 174100 User Manual

27
Table 3-2
Shipping and Support Stand Kit (174250)
Item Part Number Description Qty.
1. 174244-1 Shipping Beam, AFT 1
2. 174244-2 Shipping Beam, FORE 1
3. 75841 Bolt & Nut Assembly, (3/4 x 2.5) 8
4. 9974-10 Washer, lock (3/4) 8
5. 9997-66 Washer, flat (3/4) 8
3.1.2 List of Tools Required for Assembling and Lifting the Antenna
Table 3-3
Installation Equipment
DESCRIPTION SIZE
Ratchet 3/8" drive
Ratchet 2" drive
Ratchet 3/4" drive
Socket Set 3/8" drive, 3/8" - 3/4" plus 10mm Metric socket
Socket Set 2" drive, 2" - 1-1/8"
Socket Set 3/4" drive, 1-1/4" and 1-7/16"
Square Drive Adaptor 3/4" sq. female to 2"sq. male
Torque Wrench 3/8" drive, 5-75 ft-lbs range
Torque Wrench 2" drive, 30-250 ft-lbs range
Torque Wrench 3/4" drive, 100-600 ft-lbs range
Open End Wrench Set 7/16" - 1-1/8"
Adjustable Wrench 12"
Allen Wrench Socket Set 3/8" drive, 1/8' - 3/8"
