56
3.3.11 Installing Coaxial and Electrical Cables - Refer to Figures 3-10 and 3-11 and Table 3-11.
Table 3-11
Coaxial and Electrical Cable Installation Materials
Item Part Number Description Qty.
(From 174210 Cable Kit)
1. 174228-1 Control cable assembly - CA1 1
2. 174229 Control cable assembly - CA5 1
3. 174230 Control cable assembly - CA4 1
4. 174206-1 Coaxial cable assembly - CAX1 1
5. 174206-2 Coaxial cable assembly - CAX2 1
6. 174206-3 Coaxial cable assembly - CAX3 1
7. 174256-1 Coaxial - SSR Cont. Cable W004 1
8. 174256-2 Coaxial - SSR Diff. Cable WOOS 1
9. 174256-3 Coaxial - SSR Sum. Cable W006 1
10. 173777-8 Cable Tie 40
11. 174228-2 Control cable assembly - CA2 1
12. 174179 Grounding cable assembly 1
(From 174265 Hardware Kit)
13. 174772 Connector Weatherproofing Kit 1
14. 43211A Cable Hanger Kit 1
(Includes Qty.10 each : Hangers, Hanger Supports, 1/4-20 x 3/4" 1g. Hex Bolts,
1/4-20 Square Nuts and Installation Instructions)
15. 9963-262 Screw (114x 1.25) 8
16. 9997-42 Washer, flat (1/4) 10
17. 9974-15 Washer, lock (1/4) 10
18. 9999-57 Nut (1/4) 10
19. 9972-71 Screw (Socket head, 1/4 x 1.75) 2
To Next Page
