Andrew 174100 User Manual

32
Table 3-5
Base Interface Kit Materials (174198)
Item Part Number Description Qty.
1. 174224 Elevation Adjustment Screw 2
2. 174192-1 Shaft, Pivot, Elevation Adj. 2
3. 174101 Sleeve, Pivot Shaft 8
4. 174196 Wrench 2
5. 174195 Nut, Elev. Adj. Screw 2
6. 174188-1 Pin 8
7. 174204 Nut, Hex 2
8. 174203 Washer, lock 2
9. 174200 Washer, flat 4
10. 174104 Trunnion 2
11. 174192-2 Shaft, Pivot, Trunnion 2
12. 174141 Bracket, right 1
13. 174142 Bracket, left 1
14. 174213 Pointer, Tilt 1
15. 9963-134 Screw (1/4-20 x 518) 1
16. 9974-15 Washer, lock (1/4) 2
17. 9997-42 Washer, flat (1/4) 1
18. 9963-76 Screw (1/4-20 x 1.25) 1
19. 71964 Bolt Assembly (5/8-11 x 2.0) 8
20. 9997-60 Washer, flat (5/8) 8
21. 9974-9 Washer, lock (5/8) 8
22. 9846-7 Screw (8-32 x 2) 4
23. 9974-70 Washer, lock (#8) 4
24. 174193 Plate, Tilt Indicator 1
25. 174240-1 Bolt (7/8-9 x 3.5) 8
26. 9997-100 Washer, flat (7/8) 8
27. 9974-188 Washer, lock (7/8) 8
28. 9963-128 Screw (3/8-16 x 1.75) 4
29. 9999-60 Nut (3/8-16) 4
30. 9997-79 Washer, flat (3/8) 4
31. 9974-63 Washer, lock (3/8) 4
32. 088938 Anti Seize Compound 16 oz. can
33. 36165-34 Loctite, 243 10m1
34. 9997-92 Washer, flat (#8) 4
