52
Table 3-10
Rotary Joint-to-Dual Feed Waveguide Installation Materials (174247)
Item Part Number Description Qty.
1. 174183 WR.284 Waveguide Bend 1
2. 174184 WR.284 Waveguide Bend 1
3. 174416-1 CPR flange hardware kit 2
4. 174443 Choke flange hardware kit 2
5. 174416-2 CPR flange hardware kit, metric 2
6. 878168-1 Bracket 2
7. 9963-103 Bolt (2-13) 4
8. 9999-61 Nut (2-13) 38
9. 9997-57 Washer, flat (2) 44
10. 9974-64 Washer, lock (2) 36
11. 9934-130 Threaded rod (2-13x 12.0) 4
12. 457929-2 Spacer (waveguide) 6
13. 174590 Spacer (flex waveguide) 2
14. 174278 Rod end 2
15. 787421-2 Retainer 8
16. 173761-2 WR.284 Flexible Waveguide 2
17. 174293 Threaded rod (2-13x 14.0) 1
18. 174219 Sealant, corrosive inhibitive 1
19. 1480-0021-01 Brush 2
CAUTION
IN HANDLING ALL WAVEGUIDE COMPONENTS, TAKE CARE TO AVOID
DENTING THE WALLS, SCRATCHING OR MARRING THE FLANGE SEALING
SURFACES, TO GUARD AGAINST ENTRY OF MOISTURE AND FOREIGN
MATTER INTO THE WAVEGUIDE.
Note: When installing flange hardware, alternate the sequence of bolt tightening. This is the preferred
method of assembly for gasketed joints. Ensure that gaskets are in place on all flange connections.
The following sealant application procedure must be used for sealing all waveguide flange
connections. Refer to Figure 3-8.
1. Dip all screws into polysulfide sealant (item 18) covering all threads.
To Next Page
