SECTION 6
OPTIONAL EQUIPMENT
6.1 Obstruction Lighting Kit - Refer to Figure 6-1 and Table 6-1,
Table 6-1
Obstruction Lighting Kit (174185)
Item Part Number Description Qty.
1. 174177 Pole/Light Assembly 1
2. 173777-5 Cable Connector
1
3. 173777-7 Reducer, 1-1/4 - 2 1
4. 1674-0009-02 Tech 90 Cable 30 ft.
5. 878-0221-12 Bulb, 240V, 116 watt 4
6. 9905-47 Teflon Tape 1
7. 173777-8 Cable Tie 30
8. 174185 Copy of Drawing 2
9. 9963-653 Bolt, HH ,3/8-16 x 1.75"LG. 4
10. 9999-154 Nut, Hex, 3/8-16 4
11. 9997-36 Washer, flat, 3/8 8
12. 9974-5 Washer, lock, 3/8 4
6.1.1 Unpack the Pole/Light Assembly (item l) and ensure that all items are correct and undamaged.
6.1.2 Install Pole/Light Assembly as shown to rear face of SSR column using the 3/8" hardware supplied.
6.1.3 Install Cable (item 4) using cable ties (item 8). Apply cable ties at approximately 12 inch spaces.
Ensure that there is enough cable slack to allow cable to move freely when pole is lowered.
6.1.4 Assemble the thread reducer (item 3) and the cable connector (item 2) to the conduit box on the
Pole/Light Assembly (item 1). Wrap two or three turns of Teflon tape (item 7) to all threads.
6.1.5 Strip cable (item 4) so as to feed the three conductors through the cable connector into the conduit
box.
6.1.6 Strip the black and white conductors as required and connect all the wires to the conductors inside the
conduit box. Secure with wire nuts provided with the Pole/Light Assembly and close the conduit box.
6.1.7 Refer to the Schematic Diagram (Figure 1-4) for wiring diagram and connection to the power supply.
6.1.8 To raise or lower the pole for replacing light bulbs or other maintenance simply loosen the 3/8" nuts
on the two U-Bolts but do not remove. Raise or lower the pole as required and re-tighten the nuts to
lock the pole in position.
