4 Installation
Page 31
4.2.3. Power Connection
Before connecting electrical power to the units, the system must be grounded as
described in the previous chapter. Mains power must be connected at the mains
connector. The power supply plug is included with the Node M/C.
The correct wiring of the power supply plug is as follows:
figure 4-6 Power supply
plug
figure 4-7 Mains connector of a Node M, exemplary
Mains
Mains
Coverage antenna Donor antenna
(to mobile) (to base station)
figure 4-8 Mains connector and antenna connections of a Node C, exemplary
