5.2.9.2. Modem Output
The modem output is connected to the 20 dB modem coupler port of the DL IN
duplexer or to the N-female connector near to the BTS port to connect an external
antenna.
figure 5-13 Cable from modem to donor
duplexer
figure 5-14 Cable from modem to
external modem antenna port;
Node M
