CNC Motion Setup/Testing Utility
P/N 70000635C
Clearing a Prompt Field or Message (F1)
Press ClrFld (F1) to clear an erroneous entry. This soft key is available
during the Signal Gain and Tuning tests.
Selecting an Axis
NOTE: Select an active axis before you select an MST command
(F1–F9). If no axis is selected, the CNC displays an Error
message that prompts you to do so.
Use the following keypad keys to select and activate the corresponding
axes:
Activates/Deactivates X-axis
Activates/Deactivates Y-axis
Activates/Deactivates Z-axis
Activates/Deactivates U-axis
Activates/Deactivates Spindle Axis
U
The active axis is displayed in the upper-left corner of the General Status
area of the MST Screen.
Entering a Password
When you enter the MST Utility and press Balance (F6), Signal Gain
(F7), or Tuning (F8), the CNC prompts for the password. Type the
appropriate password and press
ENTER. Refer to 3000M CNC Setup
Utility Manual, P/N 70000499, “Section 1, Password Restricted
Parameters.”
The soft key activates. If the password has been entered successfully,
the CNC will not prompt for the password again, unless you exit and
re-enter the MST Utility.
All rights reserved. Subject to change without notice.
November 2009
4
