CNC Motion Setup/Testing Utility
P/N 70000635C
All rights reserved. Subject to change without notice.
November 2009
28
Ampli
is a good idea to occasionally check for dust build up or other
contamination.
If an amplifier should cease to operate or one or more of the fault Light
Emitting Diodes (LEDs) are lit, refer to Table 7.
NOTE: A fault can on be caused by abnormal conditions. Locate and
fier Faults
ANILAM amplifiers do not require any scheduled maintenance, although it
correct the cause of the fault before repeated recycling of power
to the amplifier to prevent possible damage.
Table 7, Amplifier – LED Indicators
Red Green Condition
Off Off No power
Off On Enabled
On Off Fault
On On Inhibit
Miscellaneous Tests (F9)
Press Misc (F9) to display a pop-up menu with eight (8) selections. The
tests marked ** on the right apply only for systems equipped with an
ANILAM AC Amplifier (P/N 33001279). These tests can only be activated
with the Servo Amplifier Test Board installed. See “Servo Amplifier Test
Board.” The pop-up does not display the ** notation.
CanBus Test
Rigid Tapping Test
Save Amp Settings**
Amplifier Test Link**
Reset Amplifier**
BackUp Amp Settings**
Restore from BackUp**
To Next Page
