Service menu continued…
Main item Sub item Item Range Set Description
2.13 Addit. settings Waste manag.
Cup amount 0-1000 250
After reaching the set total of brewer
movements, dispensing is disabled and
the display reads: Out of order – Waste
bin full
Hysteresis 0-100 20
After reaching the set total of brewer move-
ments minus the hysteresis is, the display
shows: Waste bin almost full
Time-out reset 0-50 sec. 15 s The length of time that the waste bin is al-
lowed to be removed (for emptying). When
replacing it the (internal) waste bin counter is
reset. Any display messages disappear.
Waste bin sign.. Yes/no Yes Turns off waste bin sensor software (bypass).
Cycle counter xxxxx 0-99999 This Cycle counter records the number of
vends the brewer has made. Tip: This counter
can be reset after maintenance if the brewer
has been checked.
Reset c. counter Reset counter? Reset Cycle counter (Brewer)
Perm. lter coun xxxxx 0-30.000 20.000 When the set number of (Brewer) vends is
reached the display reads ‘Replace perma-
nent  lter’ when switching on.
Reset p.  lter Reset counter? Reset the permanent  lter counter after
(preventative) replacement
PIN Code Table
No. Pincode No. Pincode
1 34242 11 13332
2 31434 12 12413
3 41343 13 43121
4 43232 14 11142
5 23341 15 21211
6 42131 16 12233
7 24244 17 34144
8 23241 18 41433
9 24323 19 31241
Table 1
10 31332 20 22324
Water Hardness Table
Water
Quality
Hardness Limescale
Indicator ...cups
°D °F °C mmol/l mgCaCo3/l
Very hard 18-30 32-55 11-18 3,2-5,3 321- 536 5000
Hard 12-18 22-32 7-18 2,2-3,2 214-321 8500
Average 8-12 15-22 5-7 1,4-2,2 268-214 12.500*
Soft 4-8 7-15 2-5 0,7-1,4 72-268 20.500
Table 2 Very soft 0-4 0-7 0-2 0- 0,7 0-72 0 = off
3. RECIPE SETTINGS
3.1 Quick recipe
First of all we would like to remind you that the cup volume (ml) and strength (%) can easily be set in
the service menu 2.1 Quick recipe (page 72 of this document).
The operator of the device (end user) also has access to this quick recipe, which is found under
section 1.4 Quick recipe (see user manual). As supplier of the device, you can remove the quick recipe
from the operator menu if desired. Go to 2.4 Settings / 2.4.9 I/0 Quick recipe via the service menu
and change Yes into No.
3.2 Model code system
The OptiFresh models have the following standard canister con gurations (table 3a & 3b):
If the device is delivered with a different canister con guration this can be given a new number using
the model code system below.
Table 3a
Model
code
Standard canister con guration
123 4 5
OptiFresh 1
1K Coffee beans
OptiFresh 2 2K Coffee beans Chocolate
OptiFresh 3 3K Coffee beans Chocolate Topping
OptiFresh 4 9K Coffee beans Chocolate Topping Instant Coffee
The OptiFresh models can be altered to one of below mentioned different canister con gurations.
These models (table 4a & 4b) are implemented in the standard software.
Table 4a
Model
code
Different canister con guration
123 4 5
OptiFresh 2
5K Coffee beans Topping
OptiFresh 2 6K Coffee beans Instant Coffee
OptiFresh 3 7K Coffee beans Instant Coffee Topping
OptiFresh 3 8K Coffee beans Chocolate Instant Coffee
OptiFresh 3 AK Coffee beans Sugar Topping
OptiFresh 4 4A Coffee beans Chocolate Topping Suiker
3.3 Button settings
The standard of programmed recipes (table 3a) can easily be transferred over the 12 recipe buttons.
See service menu 2.2 Button settings (page 72).
The optional recipes (table 4a) are already contained in the software and can easily be programmed
under one recipe button. See service menu 2.2 Button settings (page 72).
