There is a small tab on the bottom that needs to be slid sideways to unlock the
Rotary Brush Holder.
When released, grasp the Rotary Brush, lift the end up, slide to the right and
lift it up and out.
Remove any hair, thread, debris, etc. that may have caught around the
brush, end bearings, wheels or stuck in the openings.
After cleaning, refit the brush in reverse order to disassembling it.
Note: the brush can only be fitted in one direction.
Refit the Rotary Brush Holder by sliding the left end onto the drive post first,
aligning the right side then push down until the brush holder is in place.
