A-4 Functional Listings
MG369xC GPIB PM PN: 10370-10374 Rev. F A-33
SSP Selects linear step sweep. 3-115
SWP Selects analog sweep. 3-117
TEX Sets sweep trigger to external. 3-118
TRG Triggers a single sweep. 3-119
TRS Triggers a single sweep. 3-119
TSS Advances sweep to the next step in dual step sweep mode. 3-119
Table A-21. User Level Calibration GPIB Command List
Command Code Function Page
LU0 Turns off the active user level calibration table. 3-60
LU1 Activates user level calibration table #1. 3-60
LU2 Activates user level calibration table #2. 3-60
LU3 Activates user level calibration table #3. 3-61
LU4 Activates user level calibration table #4. 3-61
LU5 Activates user level calibration table #5. 3-61
LUR Prepares the MG369xC to receive 5 tables of user level calibration data
from the controller.
3-61
LUS Sends all five tables of the user level calibration data to the controller. 3-61
Table A-20. Sweep GPIB Command List (1 of 2)
Command Code Function Page
