• If connecting an RPT-485W isolating repeater module between the
AM2020/AFP1010 and the control panel, a common connection between the two
panels is not needed. However—a system common connection must be made from
the AUTOPULSE IQ-301 to RPT-485W, and the IQ-301 ground fault jumper JP9
should not be cut.
• For Receiving Unit installation and programming, refer to the AM2020/AFP1010
manual and the NIB-96 manual.
Figure 135 NFPA 72 Proprietary Fire Alarm Systems
Table 51 Proprietary Fire Alarm Systems Wiring Connections
NIB-96
MPS-24A/
MPS=24AE
TB3
T
B
3
T
B
2
T
B
1
T
B
6
TX REF RX REF OU T OUT I N IN
T
B
5
T
B
4
JP8
JP8
JP1
1
1
1
2
2
2
3
3
3
4
4
4
5
5
5
6
6
6
7
7
8
8
AC POWER
FIRE
ALARM
PRE-ALARM
WARNING
SUPERVISORY
SECURITY
ALARM
SILENCED
SYSTEM
TROUBLE
ACKNOWLEDGE
ST EP
ALARM
SILENCE
EVACUATE
HO LD 2 SE CO NDS
SYS TEM RE SET
IQ-301 Protected
Premises Unit
EIA-485 two-wire loop (Style 4), twisted pair
(power-limited and supervised)
AM2020/AFP1010 Receiving Unit
System
Common
NIB-96 IQ-301 MPS-24A
EIA-485 (+) P4 Term. 5 TB5 Term. 1
EIA-485 (–) P4 Term. 3 TB5 Term. 2
System Common T B 1 Te r m . 6 T B 3 Te r m. 6
