Figure 47 RTM-8 Module Connections
Notes on the RTM-8 module
1. Zone Relay Contact Ratings – 6 A @ 30 VDC or 300 VAC. Material: Silver
Nickel.
2. Refer to the power-limited label located on the AUTOPULSE IQ-301 cabinet door.
Make a notation on the label for each circuit used as a nonpower-limited circuit.
(Refer to the example on the label).
The RTM-8 module is not
suitable for separate
transmission of both alarm
and trouble signals to remote
station.
3. Polarity Reversal Output – 24 VDC (nominal), 10 mA maximum rated current.
Internal resistance: 1200 ohms (nominal). Intended for connection to the polarity
reversal circuit of a remote station receiving circuit (Fire•Lite RS-82) having
compatible ratings. Output is power-limited. Wiring can exit the protected
premises.
4. Municipal Box output – Supervised for open circuit. Nonpower-limited. Maximum
short current circuit: 0.6 A. Maximum open circuit voltage: 27.6 VDC. Maximum
wire resistance: 3 ohms. Wiring can exit the protected premises.
C
NO
NC
Local Energy Municipal Box LED (yellow)
Relay Disconnect Switch
Transmitter Disconnect Switch
Transmitter Disabled LED (yellow)
Relay Disabled LED (yellow)
Zone 5
Zone 6
Zone 7
Zone 8
Transmitter Output
(-) normal
(+) normal
Alarm/Trouble Polarity Reversal
Remote Station
JP1 must be cut
Alarm only Polarity Reversal
Remote Station
JP1 must be cut
Local Energy Municipal Box
Jumper JP1 is optional
Disconnected
Normal
Jumper Settings
Switch Settings
Typical Form-C Relay
Configuration
JP2 - Transmitter Module Select
JP1 - Cut for polarity
reversal remote station operation
Zone 1
Zone 2
Zone 3
Zone 4
AFP200-RTM-8.cdr
