TRANSMITTER
Power Output 4 WattsFM 1/4Watt AM
Transmission interference inferior to 4nW(-54dBm)
Frequency Response 300-3000Hz
Modulated signal distortion inferior to 5%
Output Impedance 50 ohms
RECEIVER
Sensitivity Less than 1uV for 10dB(S+N)/N
Image Rejection 70dB
Adjacent Channel Rejection 60 dB
IF Frequencies
1st 10.695MHz
2nd 455KHz
Automatic Gain Control(AGC)
Less than 10dB change in audio
Output for inputs from 10 to 50000uV
Squelch less than 1uV
Audio Output Power 2Watts
Frequency Response 300-3000Hz
Specication
GENERAL
Modulation Mode AM/FM
Frequency Range 26.965-27.405Mhz
Frequency Tolerance 0.005%
Input Voltage 13.2V
Dimensions(in mm)
112mm(L) x 143mm(W) X 30mm (H)
Weight 785g
Ferquency Control PLL Synthesizer
Operating Temperature Range -20° C TO + 55° C
Current Drain
Transmit 1.4A MAX
Receive Squelched 0.4A
VOL Max 1.3A
Antenna Connector UHF,SO-239
