WTX Series Owner’s Manual 15
3. Weave the tank band through
the four upper slots in the back
plate.
4. After exiting slot 4, the last slot in the series, direct the
tank band out the remaining slot of the buoyancy cell.
6. Repeat the process for the lower tank band.
Mounting Directly to the WTX Harness
1. Insert the tank bands
through the left slots in the
buoyancy cell and on through
corresponding web loops in
the WTX harness. Make sure
that the hook and loop of the
tank band are facing outward.
5. Slide a gripper pad on to
the tank band with the ribbed
side facing toward the cylinder.
