22 WTX Series Owner’s Manual
WARNING: DO NOT connect the inator hose to a high pres-
sure (HP) port (greater than 200 psi / 14 bar). This may cause
the hose to burst when pressurized, which can result in serious
injury. If you are unsure which regulator port is medium pres-
sure (MP) or high pressure (HP), consult your regulator owner’s
manual or your dealer before attaching the hose.
1. Remove the inator hose from the
power inator body by gripping the
grooved sleeve over the quick discon-
nect coupling with your thumb and
forenger and sliding the sleeve back.
2. Remove the port plug
from a medium pressure
(MP) port on the regula-
tor using an appropriately
sized wrench.
3. Check to ensure the o-ring is
present and in good condition. Screw
the threaded end of the hose into the
port. Tighten to 40 in/lbs (46 kg/cm)
with a 9/16" wrench.
Attaching the MP Hose to the First Stage
Apeks recommends that you bring your buoyancy compensator,
together with your regulator, to your authorized dealer for
the installation of the medium pressure (MP) inator hose
and other accessories. The retailer can also answer any
questions you may have pertaining to the information in this
manual. If it is not possible to return the BC with your regula-
tor to your authorized dealer, you may install the MP quick
disconnect inator hose by carefully performing the steps in
the following procedure.
