3.4.1 Identified Beacon Model and Configuration Message
An identified beacon model and configuration is displayed as a scrolling message to the user. This
message is composed from the following: -
Beacon Model
“MDL=1019D” Beacon model, 1019D in this example.
Enabled Options (only displayed for beacons with MCU firmware revision 4.00 onward)
“OPT=1,3” Options 1 and 3 are enabled in this example. Contact Applied Acoustics for
details.
Configuration
“CFG=AAE” AAE defined “channel” configuration (including Sigma1™).
“CFG=SIGMA2” AAE Sigma2™ configuration.
“CFG=IXB” iXBlue (IXB) compatible configuration.
“CFG=SWB” Sonardyne Wideband™ (SWB) compatible configuration.
Depending on configuration, the message is completed from the following: -
AAE Defined “Channel” Configuration
“CH=01” AAE “channel”, 01 in this example.
AAE Sigma2 Configuration
“QS=1” Sigma2 “Quickset” configuration, 1 in this example.
“WUT=0” Wake-Up Tone (WUT), 0 in this example.
“IC=00” Interrogate Code (IC), 00 in this example.
“RC=00” Reply Code (RC), 00 in this example.
“TATX=0100ms” Turn-Around-Time Extension (TATX), 100ms in this example.
