NOTE:
- Fig. 24 charge time for example only.
3.8.1 Fast Charge Activation
1000 / 1100 Series beacons feature an on-board fast charger for a typical 3 hour charge time.
Charging is activated in a short succession of steps.
Press to terminate fast charge activation and return to top tier main menu option “Fast Charge”.
Step 1 “Beacon to CHAR”
A connected beacons selector switch must be set to the dedicated fast charge position CHAR for
fast charge activation to occur, prompted by Step 1 “Beacon to CHAR”. Press
to confirm this.
Step 2 “Plug in DC PSU”
If the Smart Switch detects the 30VDC power supply unit is already inserted, Step 2 “Plug in DC
PSU” is omitted.
Fast charge activation will not proceed beyond Step 2 “Plug in DC PSU” if the Smart Switch does
not detect the 30VDC power supply unit has been inserted. The Smart Switch will display “No DC
PSU!” after is pressed. Insert the 30VDC power supply unit. Press to confirm this.
Step 3 “Start charging”
Press at Step 3 “Start charging” to activate fast charging of a connected beacon. The electronic
switch within the Smart Switch will close and fast charging will begin.
NOTE:
- Trickle charging is deactivated and serial communication with a connected beacon is
stopped on selection of fast charge main menu option.
