3.8.3 Fast Charge Termination
When fast charging terminates, the electronic switch within the Smart Switch will open, isolating
the beacon from the 30VDC power supply unit. The Smart Switch will display why fast charge
terminated, together with the time to termination in hours and minutes. Fast charge termination is
also indicated by removing the charge active icon. Fast charge termination can be due to: -
Beacon Battery Charged
Fig. 27
Beacon onboard fast charger indicates battery is fully charged, together with overall charge time in
hours and minutes.
Press to exit fast charge termination display.
Beacon Fast Charger Fault
Fig. 28
Beacon onboard fast charger has detected a fault. Check the following: -
 Has the beacon pressure relief valve vented?
 Was the beacon battery pack already fully charged? Attempting to recharge a fully charged
battery may reduce the life of the battery and cause damage.
 Is the beacon battery pack approaching the end of its operational life? Fast charging may
have timed out if the battery pack was not charging correctly.
 None of the above. Return the beacon to Applied Acoustic Engineering for evaluation.
Press to exit fast charge termination display.
NOTE: - After charge termination, the Smart Switch will now enter low power standby mode after 2
minutes of no user activity.
NOTE: - Fig. 27 ready time for example only.
NOTE: - Fig. 28 halted time for example only.
Refer 3.8.4
Refer 3.8.4
