Charging. . .
Elapsed 1h23m
T°c limit. . .
Elapsed 1h23m
3.8.2 Fast Charge Status
NOTE:
- The Smart Switch will not enter low power standby while a connected beacon is fast charging.
After fast charge activation, the Smart Switch continually monitors fast charge status information
from a connected beacon. The Smart Switch also continually monitors the inserted 30VDC power
supply unit. While fast charging, the Smart Switch displays a charging message and charge active
icon, together with elapsed time in hours and minutes. Refer Fig. 18.
Fig. 25
NOTE:
- Fig. 25 elapsed time for example only.
A temperature sensor embedded within the battery pack of a connected beacon is monitored by
the beacons onboard fast charger. If an under temperature or over temperature limit is exceeded,
fast charging will pause. The Smart Switch displays a temperature limit has been exceeded. Refer
Fig. 19. Note fast charge cycle continues, indicated by charge active icon and elapsed time
updating.
Fig. 26
NOTE:
- Fig. 26 elapsed time for example only.
Fast charging will resume when battery pack temperature is within limits. The Smart Switch again
displays a charging message and charge active icon, together with elapsed time in hours and
minutes. Refer Fig. 19.
NOTE:
- Fast charge cycle will not terminate if temperature limit exceeded.
NOTE:
- Battery pack temperature will increase toward the end of a fast charge cycle.
