1082 Smart Switch Operation Manual
CHA-1082-8000/11
__________________________________________________________________________________________________________
__________________________________________________________________________________________________________
Page 40 of 48
Operation
Modes Fast I.D. Beacon
Beacon Configuration
Responder Test
Trickle Charge
Fast Charge
Smart Switch
Firmware Field upgradeable
Electrical
Serial Comms RS232 compliant
9600 baud rate
8 data bits
1 stop bit
No parity
No flow control
Responder Test Output 5ms pulse @ RS232 electrical specification
2 second rate output
Trickle Charge 140mA maximum @ 27VDC
(30VDC power supply unit inserted)
Fast Charge 1.35A maximum @ 30VDC
(30VDC power supply unit inserted)
Included Accessories
Beacon Connection Cable 9-way ‘D’ plug to 5-way MCIL5F socket
0.5 metre
Power Supply Unit 30VDC 1.2A terminated with 2.1mm DC power plug
100-250VAC mains input
1000 Series PRV Tool
RS232 serial cable 9-way ‘D’ socket to 9-way ‘D’ plug
Mains lead I.E.C.
Although unlikely, published specifications are subject to change. Please consult the factory if a particular specification is
critical. Changes to the existing design are possible - please consult the factory for information.
CE. These units conform to the European directive 89/336/EEC for electromagnetic compatibility when used in the proper manner.
