Beacon Connection Cable
9-WAY ‘D’ PLUG MCIL5F PIGTAIL
2
1 (BLACK) /
5 (ORANGE)
3 3 (RED)
5 2 (WHITE)
9 4 (GREEN)
54321
9876
9-WAY ‘D’ PLUG
FACE VIEW
1
2
3
5
4
MCIL5F PIGTAIL
FACE VIEW
