Site requirements
Not
e: All measurements are rounded to the nearest whole- or half-unit.
Components (packaged)
WARNING! PHYSICAL INJURY HAZARD. The packages are heavy. Do not
aempt to lift or move the packages without professional assistance. Any
incorrect lifting or moving of the packages can cause serious injury.
Ensure the building clearances allow for the passage of the instrument packaging.
Package Height Length (depth) Width Weight
Instrument (on pallet) 63 cm (25 in.) 69 cm (27 in.) 42 cm (16.5 in.) 35 kg (77 lb)
Computer (laptop)
[1]
22 cm (9 in.) 42 cm (16.5 in.) 59 cm (23 in.) 7 kg (15 lbs)
Computer (minitower)
[1]
36 cm (14 in.) 47 cm (18.5 in.) 54 cm (21 in.) 14.5 kg (32 lb)
Monitor (with stand)
[1]
18 cm (7 in.) 46 cm (18 in.) 41 cm (16 in.) 7 kg (15 lbs)
[1]
A
computer (laptop or minitower), monitor, and keyboard are optional equipment.
Components (unpacked)
Ensure that the installation site bench space can accommodate the dimensions and
support the weights of the purchased conguration.
Component Height Length (depth) Width Weight
Instrument 40 cm (16 in.) 50 cm (20 in.) 27 cm (10.5 in.) 26 kg (57 lbs)
Computer (laptop)
[1]
4 cm (1.5 in.) 25 cm (10 in.) 38 cm (15 in.) 2.5 kg (5 lbs)
Computer (minitower)
[1]
36 cm (14 in.) 42 cm (16.5 in.) 17.5 cm (7 in.) 9.5 kg (21 lbs)
Monitor (with stand)
[1]
37 cm (15 in.) 18 cm (7 in.) 41 cm (16 in.) 5 kg (11 lbs)
Keyboard
[1]
3 cm (1.5 in.) 14 cm (5.5 in.) 45 cm (18 in.) 1 kg (2.5 lbs)
[1]
A
computer (laptop or minitower), monitor, and keyboard are optional equipment.
During instrument installation and maintenance, it is necessary to access the back of
the instrument. If the back of the instrument faces a wall, ensure that there is sucient
clearance on the bench to rotate the instrument for access.
IMPORTANT! For safety
, the power outlet for the instrument must be accessible.
Component Top Front Sides Back
Instrument 30 cm (12 in.) 30 cm (12 in.) 15 cm (6 in.) 15 cm (6 in.)
Computer
[1]
15 cm (6 in.) 15 cm (6 in.)
[1]
C
o-locating the computer with the instrument is optional.
Dimensions and
w
eights
Instrument
cl
earances
Site requirements
QuantStudio
3 and 5 Real-Time PCR Systems Site Preparation Guide | MAN0010405 C.0
5
