APT 8512 - Environmental Conditions

© Ikonix USA
7
sheathed exible cord according to IEC 60227, designation H03 VV-F or H03
VVH2-F
(for equipment mass not exceeding 3 kg), or H05 VV-F or H05 VVH2-F2
(for equipment mass exceeding 3 kg), and be rated for at least 3G 0.75 mm² (for
rated current up to 10 A) or 3G 1.0mm² (for rated current over 10 A up to 16 A)
wire or larger, and the length of the cord does not exceed 2 m must be used.
The following chart lists the wire conguration that must be used for
connection to the input and output of the dierent models:
The rear panel terminal covers should be used to prevent electric shock. The
input/output terminals must be covered when using this product.
2.6 Environmental Conditions
Operating Environment (for indoor use)
Temperatures: 0º - 40º C (32º - 104º F) Relative humidity: 20% - 80%
Altitude: 2,000 meters (6,562 feet) Over Voltage Category: OVC II
Pollution Degree: PD2
Do not block any ventilation openings to prevent overheating of the
equipment. Keep the ventilation slits uncovered during operation. Failure
to do so could cause the instrument to overheat and may damage internal
components.
The instrument should also be protected against temperature extremes
which may cause condensation within the instrument. If the instrument is
used in a matter not specied by the manufacturer, the protection provided
by the instrument may be impaired. The instrument should also be protected
against temperature extremes which may cause condensation within the
instrument.
Storage and Shipping Environment
This instrument may be stored or shipped in environments with the following limits:
Temperature………………..-40
º
to +55
º
C
Altitude…………………….7,620 meters (25,000 feet)
Model Input Output
8512 12 AWG / 2.5mm² 14 AWG / 1.5 mm²
8520 10 AWG / 4mm² 12 AWG / 2.5 mm²
8540 10 AWG / 4 mm² 8 AWG / 6 mm²
