5.8 Error and Failure Messages
The APT 8500 Series power sources can display several error or failure messages during an abnormal
condition. When an abnormal condition occurs, the output will disable and the alarm will sound. The
OUTPUT/RESET LED indicator will also begin ashing. See sections 3.1 Specications and 4.2 System for
details on the available ranges for all test and system parameters.
All error messages occur in abnormal conditions and therefore must be
recorded. Check the cause of the error to ensure the problem is eliminated
before restarting the operation, or contact Associated Power Technologies, or
our ocial distributors for further assistance.
The following table describes all types of error and failure messages that can be displayed on the screen
during an abnormal condition while the power source is operating
Code Description
Process to Clear
Press EXIT key Wait 5sec,
Press EXIT key
Reboot. If error
message repeats
contact manufacturer
Contact
Manufacturer
OVP_PEAK
Displayed if the output voltage
exceeds the peak output
voltage range:
Hi - 482.2V, Lo - 241.1V
•
OVP
Displayed if the output voltage
exceeds the output voltage
range:
Hi - 460.26V, Lo - 230.13V
•
OCP_PEAK
Displayed if the output current
exceeds the peak (Inrush)
output current by 10% in the
Lo range (0-155V) and by
20% in the Hi range (0-310V).
•
OCP
Displayed when the output
current exceeds 10% of the
maximum output current
range.
•
OPP_PEAK
Displayed if the power output
exceeds the peak power
output range:
Model 8505: 3111W
Model 8512: 7778W
Model 8520: 12445W
Model 8540: 24890W
•
OPP
Displayed if the power output
exceeds the maximum power
output by 10%.
•
