Models
8505 8512 8520 8540
Measurement
Peak Current
Measurement
(Programmable Option)
Range 0.0 - 20.0Apk 0.0 - 50.0Apk 0.0 - 80.0Apk 0.0 -160.0Apk
Resolution 0.1A
Accuracy ± (0.5% of reading
+8 counts)
± (0.5% of reading
+12 counts)
Reactive Power
Measurement
(Programmable Option)
Range L 0.0 - 75.0VAR 0.0 - 300.0VAR
-
H 60 - 625VAR 240 - 1563VAR 240 - 2500VAR 0 - 5000VAR
Resolution L .01A
H 0.01A
Calculated Formula
(VA)
2
- (W)
2
Crest Factor
Measurement
(Programmable Option)
Range 0.00 - 10.00
Resolution 0.01
Calculated Formula Ap / A
Protection
Software OCP
(102% < Io ≤110%), >5 second output shut down
>110% of full rated current, <1.5 second output shut down
Output Short Shut Down Speed <1 second
Software OPP
≤110% of full rated current (102% < Po ≤110%), > 5 second output shut down
>110% of full rated current, <1.5 second output shut down
Software OVP Over voltage 105% of full rated voltage
Software VSENSE OVP
H When measurement voltage exceeds setting voltage 10V
L When measurement voltage exceeds setting voltage 5V
Software VSENSE LVP
H When measurement voltage is lower than setting voltage 10V
L When measurement voltage is lower than setting voltage 5V
Hardware OTP
Temperature over 108°C on power component of the PFC and DDC
Temperature over 100°C on heatsink of the power amplifier
Software RCP
(Reverse Current Protection)
When reverse power over 5% of full rated power
Hardware FAN FAIL When the cooling fan is blocked and fails
Response Time (Tr/Tf) (*12) 275 - 400us (Typical)
Max DUT Input Capacitance ≤ 7.5uF
