51
Code Description
Process to Clear
Press EXIT key Wait 5sec,
Press EXIT key
Reboot. If error
message repeats
contact manufacturer
Contact
Manufacturer
PFC_OCP
Displayed when the maximum
current during the power
factor correction is as follows:
Model 8505 > 10Arms
Model 8512 > 22Arms
Model 8520 > 35Arms
• •
PFC_OTP
Displayed when the
temperature of the DDC side
MOS on the PDC board
reaches 108°C.
• •
DD_OVP
Displayed when the output
voltage of the DDC board is
detected to be greater than
342V.
• •
DD_LVP
Displayed when the output
voltage of the DDC board is
detected to be less than 272V.
• •
DD_OCP
Displayed when the output
current of the DDC board is as
follows:
Model 8505 > 3.35Arms
Model 8512 > 6.88Arms
Model 8520 > 11.34Arms
• •
DD_OTP
Displayed when the
temperature of the DD side
MOS on the DDC board
reaches 108°C.
• •
CALIBRATION
ERROR
Displayed when:
a. No calibration value is
detected.
b. An error occurs during the
calibration process.
•
P-Hi
Displayed when the value of
real power (W) exceeds the
P-Hi setting.
•
P-Lo
Displayed when the value of
real power stays below the
P-Lo setting
•
AP-Hi
Displayed when the peak
current value exceeds the
AP-Hi setting.
•
AP-Lo
Displayed when the peak
current value stays below the
AP-Lo setting.
•
PF-Hi
Displayed when the power
factor value exceeds the PF-Hi
setting.
•
PF-Lo
Displayed when the power
factor value stays below the
PF-Lo setting.
•
