AquaLab 4TE Series User Manual

AquaLab 10 DUO OPERATION (OPTIONAL)
10.1 Obtaining Product Isotherm Models
Since the isotherm relationship for each product is unique, each prod-
uct isotherm model must be determined experimentally. This only
needs to be done once, but must be done prior to testing moisture
content with the DUO.
There are several strategies that can be used to generate models.
Please contact Decagon for information on model development.
10.2 Loading and Organizing Product Models
A Product model must be loaded into the Series 4TE DUO before
it can calculate moisture content. Each product must have its own
model and the model can either be loaded at the factory by Decagon
or by using the AquaLink 4 software program. This software is in-
cluded with each DUO purchase or upgrade. Product model files
generated by Decagon are sent to customers via e-mail and can then
be loaded into the instrument by connecting to the instrument using
the AquaLink 4 software.
Figure 4: AquaLink 4 Model Loading Tool
The software uses a model loading tool to add and remove product
models from the Series 4TE DUO, allowing the user to control and
organize their product models. Up to 100 models can be stored on
the instrument. The AquaLink 4 software can also download data
51

AquaLab 4TE Series Specifications

General

Accuracy	±0.003 aw
Temperature Control	15 to 50 °C
Measurement Time	5 minutes
Measurement Principle	Chilled Mirror Dewpoint
Resolution	0.0001 aw
Temperature Accuracy	±0.1 °C
Communication	USB, RS-232
Display	LCD
Measurement Range	0.03 to 1.00 aw
Operating Temperature	4-50 °C (39-122 °F)
Data Storage	8000 readings
Power Supply	50/60 Hz
Storage Temperature	-20 to 50 °C
