Aquatec®ORCA/ORCAF/ORCAXL
WARNING!
Riskofinjuryanddamage!
–Onlysetupthebathliftinbathtubsthatcomplywith
thespecificationsofthefollowingtable.
–Ifalateraloverflowispresentinthebathtub,usethe
specialsideflaps(availableasanaccessory).
A
B
C
H
E
80 mm
A
Tublength,
bottom
≥800mm
B
Tubwidth,
bottom(inside)
min.280mm
C
Tubwidth,at
80mmheight
(inside)
≥430mm
E
Tubwidth
(outside)
580-690mm(withspecialsideflaps)
700-740mm(withstandardsideflaps)
750-1000mm(withspecialsideflaps)
H
Tubheight
(inside)
≤420mm
(withheightadapter,max.+60mm)
IMPORTANT!
–Ensurethatthesuctioncupsaremounted.
–Ensurethatthebatteryinthehandcontrolischarged.
–Ensurethatthespindlefootisfullyinserted.
–Whenliftingbathliftcomponents,remember
tocorrectlyassesstheweights,seesection9.1
Dimensionsandweight,page22
.
–Ifahandrailismountedattheinsideofthebathtub,
usethesideflapdiverters(availableasanaccessory).
–Foldthesideflapsoutwardsbeforeraisingthe
backrest.
101574469-A
