ARB INTENSITY IQ - Care and Maintenance; Specifications and Features

Care and Maintenance
• Clean only with warm soapy water and a sponge or sot brush. DO NOT use solvents, scourers or hard bristle
brushes. DO NOT use harsh wash chemicals as these will remove the protective clear coat from the lens.
• There are no serviceable components inside the light – DO NOT disassemble.
• Ensure all electrical connectors and the wiring loom are secured away from sharp edges and hot surfaces.
• Regularly check all mounting and adjusting bolts to ensure they are secure and tight.
• If your light requires further service or repair, return it to your local ARB distributor.
Input 11-V
Power 1W @ 13.V
Current Draw 12.A @ 13.V
Super Spot 4 x Cree XLamp
®
XP-P
Spot 2 x Cree XLamp
®
XM-L,
3 x XLamp
®
XP-P
Flood 18 x Cree XLamp
®
XT-E
Mid Range 4 x Cree XLamp
®
XM-L
Output – Raw
Max Spot 7,070 lumens
Max Flood 14,060 lumens
Output – Efective
Max Combo 6,265 lumens
Max Spot 6,613 lumens
Max Flood 6,666 lumens
Distance @ 1 Lux (Pair Lights)
Max Combo 1,105m @ 1 lux
Max Spot 1,350m @ 1 lux
Max Flood 900m @ 1 lux
Spread Customisable
Input Cable Length 450mm
Operating Temperature
-40
°
C to +80
°
C
(-40
°
F to +176
°
F)
Colour Temperature 5,700-6,200k
Weight 3.8kg (8.4lbs)
Compliance
• CE
• CISPR CL
• FCC
3-pin Connector High Amp, waterproof
Dimensions Width x Height x Depth
220mm x 215mm x 142mm
(8.7in x 8.5in x 5.6in)
Operated by Switch, LINX or smartphone
Functions Work light
Courtesy light
Light fading
Euro mode (UNECE R)
Warranty 3 years
Specifications and Features
214mm (
8.5in)
220mm (
8.7in) 142mm ( 5.6in)
• IP
• RCM
• RoHS
• UNECE R
• UNECE R (when set to Euro mode)
• UKCA
