Arcam AVR11 User Manual

EN-40
Specications
Stereo line inputs
Maximum input 4.5V rms
Nominal sensitivity 1V, 2V, 4V (user adjustable)
Input impedance 47kΩ
Signal/noise ratio (A-wtd ref 100W)
normal/stereo direct
93dB/110dB
Frequency response 20Hz—20kHz ± 0.1dB
Preamplier outputs
Nominal output level (single-ended/balanced) 1V RMS/2V RMS
Output impedance 560Ω
THD+N (20Hz—20kHz) –100dB
Headphone output
Maximum output level into 32Ω 5Vrms
Output impedance <100Ω
General
Mains voltage 110–120V or 220–240V, 50 –60Hz
Power consumption (maximum) 50W (Thermal dissipation approx. 170 BTU/hour)
Power consumption (idle, typical) 40W (Thermal dissipation approx. 170 BTU/hour)
Power consumption (standby) <0.5W
Dimensions W x D
(including speaker terminals) x H (including feet)
433 x 425 x 171mm
Weight (net) 10.6kg
Weight (packed) 13.9kg
Supplied accessories Mains lead
Remote control with 2 x AAA batteries
Manual
DAB/FM aerial
3 x WiFi/Bluetooth antennas
Calibration microphone
USB cable
E&OE
NOTE: All specification values are typical unless otherwise stated.
AV41
Continual improvement policy: Arcam has a policy of
continual improvement for its products. This means
that designs and specications are subject to change
without notice.
AVR31
Continuous power output, per channel, 8/4
2 channels driven, 20Hz - 20kHz, <0.02% THD 120W/200W
2 channels driven, 1kHz, 0.2% THD 140W/220W
7 channels driven, 1kHz, 0.2% THD 100W/180W
Residual noise & hum (A-wtd) <0.15mV
Stereo line inputs
Maximum input 4.5V rms
Nominal sensitivity 1V, 2V, 4V (user adjustable)
Input impedance 47kΩ
Signal/noise ratio (A-wtd ref 100W) normal/stereo direct 93dB/110dB
Frequency response 20Hz—20kHz ± 0.1dB
Preamplier outputs
Nominal output level 1V RMS
Output impedance 560Ω
THD+N (20Hz—20kHz) –100dB
Headphone output
Maximum output level into 32Ω 5Vrms
Output impedance <100Ω
General
Mains voltage 110–120V or 220–240V, 50 –60Hz
Power consumption (maximum) 1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical) 100W (Thermal dissipation approx. 340 BTU/hour)
Power consumption (standby) <0.5W
Dimensions W x D
(including speaker terminals) x H (including feet)
433 x 425 x 171mm
Weight (net) 18.1kg
Weight (packed) 21.4kg
Supplied accessories Mains lead
Remote control with 2 x AAA batteries
Manual
DAB/FM aerial
3 x WiFi/Bluetooth antennas
Calibration microphone
USB cable
E&OE
NOTE: All specification values are typical unless otherwise stated.

Arcam AVR11 Specifications

General

Type	AV Receiver
Power Output	85W per channel (8 ohms, 2 channels driven)
Total Harmonic Distortion	0.02%
Input Impedance	47k Ohms
HDMI Inputs	7
HDMI Outputs	2
4K (UHD) passthrough	Yes
8K (UHD) passthrough	No
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Dirac Live	Yes
Roon Ready	Yes
Bluetooth	Yes
Wi-Fi	Yes
Ethernet	Yes
Spotify Connect	Yes
USB Port	Yes
Frequency Response	20Hz - 20kHz
Signal-to-Noise Ratio	100dB
AirPlay	Yes
Supported Audio Formats	FLAC, WAV, ALAC, MP3, AAC, WMA
Dimensions	433 x 171 x 425 mm
