E-28
SAT Device Mode
e
z
Device Mode button congures the CR102
to control the functions of a satellite receiver. You will
need to congure this Device Mode to work with your
equipment. Pressing this button also selects SAT as the
AVR400 source.
P
Toggles power between standby and on
0
…
9
Functions as original remote number key.
PHONO
E
Selects Display input on the AVR400.
TV/AV
r
Toggles between the available inputs on
your satellite receiver
S
Modies many keys (see individual key
descriptions, below)
AUX
H
Selects multichannel (
MCH) input on the
AVR400.
SHIFT +
H
selects AUX input on the
AVR400.
NET
e
Selects
IPOD input on the AVR400
SHIFT +
e
selects network (NET) internal
input on the AVR400
Navigate menus.
OK conrms a setting (equivalent to ‘Enter’
or ‘Select’ on some remotes).
M
Controls Backup function, if available.
U
Performs same function as on original
remote, if available.
D
On some Satellite and Cable set top boxes
this key functions as the Guide key to open
the EPG (Electronic Program Guide).
@
Toggles the mute function.
By default this key operates the AVR400 Mute
]
Channel down
[
Channel up
- +
Decrease (
) or increase (+) AVR400 volume
)
Fast rewind
$
Starts the playback
&
Toggles pause of playback
(
Fast forward
!
(not used)
#
Stop playback
%
Start recording
h
(not used)
u
(RED)
Duplicates function of RED key for some
Satellite and Cable set-top boxes
t
(GREEN)
Duplicates function of GREEN key for some
Satellite and Cable set-top boxes
o
(yELLOw)
Duplicates function of YELLOW key for some
Satellite and Cable set-top boxes
b
(BLUE)
Duplicates function of BLUE key for some
Satellite and Cable set-top boxes
AV Device Mode
e
a
Device Mode button congures the CR102 to
control the functions of a television or other display
device. You will need to congure this Device Mode to
work with your equipment. Pressing this button also
selects AV as the AVR400 source.
P
Toggles power between standby and on.
(Some TVs require you to use a number
key to turn them on.)
0
…
9
Functions as original remote number key –
usually for channel selection.
PHONO
E
Selects Display input on the AVR400.
TV/AV
r
Toggles between the available inputs on
your display device (e.g. TV/AV)
S
Modies many keys (see individual key
descriptions, below)
AUX
H
Selects multichannel (
MCH) input on the
AVR400.
SHIFT +
H
selects AUX input on the
AVR400.
Navigate setup and programme selection
menus.
OK conrms a selection (equivalent to
‘Enter’ or ‘Select’ on some remotes).
M
EXIT function on some models.
U
Functions as original remote key, if
available.
D
Display INFO or OSD (On Screen Display)
function, if available.
@
Toggles the mute function.
By default this key operates the AVR400
Mute
]
Channel down
[
Channel up
- +
Decrease (
) and increase (+) AVR400
volume.
)
Toggles TEXT page on/o
$
TEXT page o
&
Turns Programme-In-Programme (PIP)
on, if available
(
Activates PIP move, if available
!
Activates PIP swap, if available
#
Activates PIP freeze, if available
%
Activates PIP channel up, if available
h
Activates PIP channel down, if available
u
(RED)
Duplicates function of RED key for Text TV
t
(GREEN)
Duplicates function of GREEN key for Text
TV
o
(yELLOw)
Duplicates function of YELLOW key for Text
TV
b
(BLUE)
Duplicates function of BLUE key for Text
TV
